Product Introduction
Plastic Multicolor Printing Machine – Professional Flexible Packaging Solution
At Rizhao Jinlida Plastic Co., Ltd., we bring over 30 a long time of industry ability to convey high-precision printing hardware planned for PE, PP, PVC, and POF plastic movies. Our plastic multicolor printing machines include progressed servo-driven enrollment frameworks keeping up resiliences inside ±0.1mm, computerized pressure control, and multi-color setups (2 to 6 colors). With printing speeds coming to 30–180m/min and widths from 600mm to 1500mm, our hardware handles complex design whereas guaranteeing dynamic, fade-resistant comes about. Traded to 40+ nations and sponsored by ISO quality certification, we offer assistance you accomplish reliable, professional-grade printing for nourishment bundling, pharmaceutical movies, and mechanical applications.
Key Features
Advanced Low-Temperature Drying Technology
Specially developed for water-based ink printing, the machine adopts a stable 45℃–55℃ low-temperature drying process to protect PE and PP films from deformation, shrinkage, stretching, and wrinkling, maintaining excellent print quality.
Extended Drying Air Circulation Channel
The optimized long drying tunnel enables deep and uniform drying from the ink surface to the inner layer, preventing ink adhesion, smudging, and insufficient drying during continuous high-speed printing.
High-Efficiency Energy-Saving Air Circulation System
Featuring an insulated chamber design and efficient hot air recycling technology, the system significantly improves thermal utilization and reduces energy consumption by more than 60% compared with conventional dryers.
Smart PLC Automatic Control
The intelligent control system enables precise temperature regulation, airflow adjustment, and speed synchronization, ensuring simple operation and reliable production performance.
Multiple Drive Options Available
With mechanical, synchronous belt, and full servo drive configurations, the machine can be customized to match different production scales and printing requirements.
Green & Sustainable Printing Support
Designed for water-based ink printing, the dryer helps lower VOC emissions, create a cleaner production environment, and support eco-friendly manufacturing.
Ideal Applications:
Flexible packaging printing, PE/PP film printing, water-based ink applications, and sustainable printing solutions.
What Makes Our Printing Technology Different
When you contribute in a product, you're not fair buying gear. You're choosing a arrangement that tackles genuine generation challenges.
Our machines combine flexographic and gravure printing innovations. This implies you can apply different ink layers in a single pass. No more wasteful auxiliary handling. No more enrollment misalignment from substrate stretching.
The coordinates crown treatment framework raises the plastic's surface pressure. This guarantees solid ink grip indeed on non-porous materials like PE and PP movies. Your printed plans remain dynamic and strong all through the item lifecycle.
Core Applications Across Industries
Flexible Food Packaging
You can create multi-layer covered pockets with photographic-quality CMYK design. Our machines work consistently in high-humidity cleanroom situations. They keep up color thickness and exactness indeed beneath requesting conditions.
Pharmaceutical Packaging
Print basic dose informational and anti-counterfeiting markers on PVC or PVDC movies. Exactness and neatness are ensured. Your compliance necessities are met without compromise.
Industrial Shrink Sleeves
High-speed printing on PETG or PVC heat-shrinkable movies gets to be easy. The ink versatility guarantees illustrations stay undistorted indeed after 70% shrinkage in warm tunnels.
Commercial Packaging Bags
Our plastic multicolor printing machines exceed expectations at printing on shopping sacks and tote packs with load-bearing capacities from 8 to 50kg. Dynamic branding remains intaglio through rehashed use.
Plastic Multicolor Printing Machine Specifications
| Parameter | Specification |
|---|---|
| Applicable Materials | PE, PP, POF, PVC plastic film, bags, composite film |
| Color Configurations | 2-color / 4-color / 6-color |
| Printing Width | 600mm / 800mm / 1000mm / 1200mm / 1500mm (common: 800-1200mm) |
| Printing Speed | Standard: 30–80m/min / High-speed: 80–180m/min |
| Plate Type | Flexo: flexible resin plate / Gravure: engraved chrome-plated cylinder |
| Plate Circumference | 300–800mm |
| Drying System | Hot air circulation (40–120℃) / Electric, steam, or thermal oil heating |
| Max Unwinding Diameter | ≤800mm |
| Max Rewinding Diameter | ≤800mm |
| Total Power | 2-color: 5–10kW / 4-color: 10–20kW / 6-color: 18–30kW |
| Control System | PLC touchscreen, automatic color registration, tension control, web guiding |
Why Partner With Rizhao Jinlida
Manufacturing Excellence
Our 8,600㎡ office houses progressed gravure printing machines with photoelectric adjustment frameworks. Over 100 talented specialists, counting 40+ specialized experts, guarantee each machine meets strict quality standards.
Proven Global Experience
We've traded to more than 40 nations over Europe, North America, Australia, and Asia. You advantage from our profound understanding of universal bundling benchmarks and assorted advertise requirements.
24-Hour Support
Production questions? Specialized concerns? Our group reacts rapidly to keep your operations running easily. We're committed to your long-term success.
Quality Assurance
ISO certification and China QS measures ensure steady execution. Our closed-loop pressure control framework anticipates film extending amid high-speed runs. Free servo engines at each color station dispose of enlistment float.
Quality Control You Can Trust
Professional buyers value rigorous inspection protocols. Here's how we ensure your investment delivers lasting ROI:
Registration Testing: We verify color overlaps remain consistent at both slow and maximum production speeds using stroboscopic video inspection.
Ink Adhesion: Every sample undergoes cross-hatch tape tests to confirm strong ink-to-plastic bonding.
Drying Efficiency: We measure residual solvent levels to prevent ink blocking or migration issues.
Mechanical Precision: Concentricity checks on printing cylinders prevent ghosting or banding effects.
Tension Stability: Load cells and dancing rollers maintain constant substrate tension across varying roll diameters.
Frequently Asked Questions
Q: How does your machine prevent film stretching during high-speed runs?
A: Our machines use a closed-loop tension control system with load cells and dancing rollers. This maintains constant substrate tension and compensates for material elasticity in real-time.
Q: What causes color misalignment, and how do you solve it?
A: Registration drift typically stems from thermal expansion or mechanical backlash. We use independent servo motors at each color station for precise micro-adjustments during operation.
Q: Can your machines handle eco-friendly water-based inks on plastic?
A: Absolutely. Our enhanced drying systems with higher airflow and corona surface treatment raise the plastic's dyne level. This ensures excellent wetting for water-based inks.
Q: How often should maintenance be performed?
A: We recommend daily cleaning of anilox rollers using ultrasonic cleaners or specialized solutions. This prevents ink buildup and maintains consistent color quality.
Q: What safety certifications do your machines carry?
A: Our equipment meets CE certification standards and includes emergency stop circuits with interlocked guarding to protect operators from high-speed rotating components.
Get Your Custom Solution Today
Ready to upgrade your packaging production? Our plastic multicolor printing machine's team understands your unique requirements. Contact us at 18663311788@139.com to discuss your project specifications and receive a detailed quotation.
